| Nambari ya Sehemu | TM080XPH01 |
| Chapa | Tianma |
| Ukubwa | 8.0 |
| Maombi | MP4 |
| Azimio | 1280×768 |
| Muundo | CELL |
| Mwangaza | 0 |
| CR | 400:1 |
| Rangi | 262K |
| Mwangaza nyuma | No B/L |
| Kiolesura | Mini LVDS |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM080XPH01 |
| aina ya paneli | a-Si TFT-LCD , CELL |
| saizi ya paneli | 8.0 inch |
| azimio | 1280(RGB)×768 , WXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 173.76×104.256 mm |
| muhtasari | 181×112.8×3.05 mm |
| uso | |
| kioo kina | 0.50+0.50 mm |
| uwiano wa utofautishaji | 400:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193150% |
| wakati wa majibu | 25/25 (Typ.)(Tr/Td) |
| angle ya kutazama | 70/70/65/65 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| kiolesura cha ishara | Mini LVDS, 40 pins |
| voltage ya pembejeo | 3.3/12.5/22.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| maombi | MP4 |
| A065VL01 V2 | AUO | 6.5 | 800×480 |
| AT070TN92 V.3 | Innolux | 7.0 | 800×480 |
| AT070TNA2 V.1 | Innolux | 7.0 | 1024×600 |
| BA070WS1-300 | BOE | 7.0 | 1024×600 |
| CLAA070ND02 | CPT | 7.0 | 1024×600 |
| CLAA089NA0BCW | CPT | 8.9 | 1024×600 |
| LB070WV4-TD02 | LG Display | 7.0 | 800×480 |
| LB070WV6-TD06 | LG Display | 7.0 | 800×480 |
| LMS700JF01-001 | Samsung | 7.0 | 1024×600 |
| LMS700KF21 | Samsung | 7.0 | 800×480 |
