| Nambari ya Sehemu | TM097TDH02 |
| Chapa | Tianma |
| Ukubwa | 9.7 |
| Maombi | PAD |
| Azimio | 1024×768 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | AVIC |
| mfano wa paneli | TM097TDH02 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 9.7 inch |
| azimio | 1024(RGB)×768 , XGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 196.608×147.456 mm |
| muhtasari | 210.21×166.3×5.85 mm |
| uso | Clear |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193150% |
| wakati wa majibu | 20 (Typ.)(Tr+Td) |
| angle ya kutazama | 70/60/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 6S6PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
