| Nambari ya Sehemu | TM097TDHG04-02 |
| Chapa | TIANMA |
| Ukubwa | 9.7 |
| Maombi | Pad & Tablet Industr |
| Azimio | 1024×768 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | 6S6P |
| Kiolesura | LVDS |
| chapa ya paneli | TIANMA |
| saizi ya paneli | 9.7" |
| azimio | 1024(RGB)×768, XGA, 132PPI |
| eneo la maonyesho | 196.608(W)×147.456(H) mm |
| saizi ya muhtasari | 210.2(W)×166.3(H) ×5.85(D) mm |
| mwangaza | 350 cd/m² (Typ.) |
| angle ya kutazama | 70/70/60/70 (Typ.)(CR≥10) |
| mwonekano bora zaidi | 12 o'clock |
| kuonyesha rangi | 262K 50% NTSC |
| masafa | 60Hz |
| uzito wa paneli | 200g (Typ.) |
| kiolesura cha ishara | LVDS (1 ch, 6-bit) , 30 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| mfano wa paneli | TM097TDHG04-02 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | 200.91(W)×152.27(H) mm |
| uso | Clear |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| wakati wa majibu | 20/25 (Typ./Max.)(Tr+Td) |
| aina ya taa | 6S6P WLED , 30K hours , Without Driver |
| skrini ya kugusa | Without |
| maombi | Pad & Tablet Industrial |
