| Nambari ya Sehemu | TM097TDHG04-62 |
| Chapa | TIANMA |
| Ukubwa | 9.7 |
| Maombi | Pad & Tablet Industr |
| Azimio | 1024×768 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | TIANMA |
| ukubwa wa diagonal | 9.7 inch |
| muundo wa pixel | 1024(RGB)×768 [XGA] 132PPI |
| eneo la kazi | 196.608(H)×147.456(V) mm |
| eneo la bezel | 200.91(H)×152.27(V) mm |
| mwangaza | 350 cd/m² (Typ.) |
| tazama mwelekeo | 12 o'clock |
| angle ya kutazama | 70/70/60/70 (Typ.)(CR≥10) |
| rangi ya msaada | 262K 50% NTSC |
| uzito | 200g (Typ.) |
| kiwango cha fremu | 60Hz |
| aina ya kiolesura | LVDS (1 ch, 6-bit) , 30 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| mfano | TM097TDHG04-62 |
| aina | a-Si TFT-LCD , LCM |
| usanidi | RGB Vertical Stripe |
| muhtasari dim. | 210.2(H)×166.3(V) ×6.5(D) mm |
| matibabu | Clear |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| wakati wa majibu | 20/25 (Typ./Max.)(Tr+Td) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| chanzo cha mwanga | WLED [6S6P] , 30K hours , W/O Driver |
| iliyoundwa kwa ajili ya | Pad & Tablet Industrial |
| jopo la kugusa | Without |
