| Nambari ya Sehemu | TM103XDHP01 |
| Chapa | TIANMA |
| Ukubwa | 10.3 |
| Maombi | Automotive Display |
| Azimio | 1920×720 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | TIANMA |
| mfano | TM103XDHP01 |
| ukubwa wa diagonal | 10.3 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1920(RGB)×720 200PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 243.65(H)×91.37(V) mm |
| muhtasari dim. | - |
| mwangaza | - |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 35 (Typ.)(Tr+Td) |
| angle ya kutazama | 88/88/88/88 (Typ.)(CR≥10) |
| hali ya uendeshaji | SFT, Normally Black, Transmissive |
| rangi ya msaada | 16.7M |
| chanzo cha mwanga | WLED |
| uzito | - |
| iliyoundwa kwa ajili ya | Automotive Display |
| aina ya kiolesura | LVDS (2 ch, 8-bit) , 50 pins FPC |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C |
