| Nambari ya Sehemu | TM103XDKP05 |
| Chapa | TIANMA |
| Ukubwa | 10.3 |
| Maombi | Outdoor High Brightn |
| Azimio | 1920×720 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | |
| chapa | TIANMA |
| mfano | TM103XDKP05 |
| ukubwa wa diagonal | 10.3 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1920(RGB)×720 200PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 243.648(H)×91.368(V) mm |
| muhtasari dim. | 259.84(H)×109.3(V) mm |
| eneo la bezel | - |
| matibabu | Hard coating, Reflection 5.5% (Typ.) |
| mwangaza | 1000 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 88/88/88/88 (Typ.)(CR≥10) |
| hali ya uendeshaji | SFT, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 75% NTSC |
| chanzo cha mwanga | WLED [9S4P] , 10K hours , W/O Driver |
| uzito | 300g (Typ.) |
| iliyoundwa kwa ajili ya | Outdoor High Brightness Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
