| Nambari ya Sehemu | TM103XDKP38-00 |
| Chapa | TIANMA |
| Ukubwa | 10.3 |
| Maombi | Outdoor High Brightn |
| Azimio | 1920×720 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 8S3P |
| Kiolesura | LVDS |
| mtengenezaji | TIANMA |
| jina la mfano | TM103XDKP38-00 |
| ukubwa wa skrini | 10.3 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 1920(RGB)×720 200PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 243.648 × 91.368 (H×V) |
| muhtasari(mm) | 261.04 × 109.3 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Hard coating, Reflection 5.5% (Typ.) |
| mwangaza | 800 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 88/88/88/88 (Typ.)(CR≥10) |
| majibu | 20 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | SFT, Normally Black, Transmissive |
| kina cha rangi | 16.7M 74% NTSC |
| backlight | 8S3P WLED , 10K hours , No Driver |
| wingi | TBD |
| kutumika kwa | Outdoor High Brightness Automotive Display |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (2 ch, 8-bit) , Connector 50 pins |
| usambazaji wa voltage | 3.3/3.3V (Typ.)(VDD/AVDD) |
| max. ukadiriaji | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
