| Nambari ya Sehemu | TM116VDSP03 |
| Chapa | TIANMA |
| Ukubwa | 11.6 |
| Maombi | Industrial Outdoor H |
| Azimio | 1920×1080 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 9S6P |
| Kiolesura | LVDS |
| mtengenezaji | TIANMA |
| jina la mfano | TM116VDSP03 |
| ukubwa wa skrini | 11.6 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 1920(RGB)×1080 (FHD) 190PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 256.32 × 144.18 (H×V) |
| muhtasari(mm) | 273.5 × 166.5 × 11.5 (H×V×D) |
| eneo la bezel(mm) | 259.31 × 148.73 (H×V) |
| matibabu | Hard coating |
| mwangaza | 1000 cd/m² (Typ.) |
| uwiano wa utofautishaji | 900 : 1 (Typ.) (TM) |
| angle ya kutazama | 88/88/88/88 (Typ.)(CR≥10) |
| majibu | 25 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | SFT, Normally Black, Transmissive |
| kina cha rangi | 16.7M 70% NTSC |
| backlight | 9S6P WLED , 50K hours , No Driver |
| wingi | TBD |
| kutumika kwa | Industrial Outdoor High Brightness |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (2 ch, 8-bit) , 30 pins Connector |
| usambazaji wa voltage | 3.3/10.7/20/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| max. ukadiriaji | Storage Temp.: -30 ~ 85 °C Operating Temp.: -20 ~ 70 °C |
