| Nambari ya Sehemu | TM121JDSG10 |
| Chapa | TIANMA |
| Ukubwa | 12.1 |
| Maombi | Industrial |
| Azimio | 1280×800 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| mtengenezaji | TIANMA |
| jina la mfano | TM121JDSG10 |
| ukubwa wa skrini | 12.1 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 1280(RGB)×800 (WXGA) 124PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 261.12 × 163.2 (H×V) |
| muhtasari(mm) | 278 × 184 × 10.4 (H×V×D) |
| eneo la bezel(mm) | 262.12 × 164.2 (H×V) |
| matibabu | Antiglare |
| mwangaza | 450 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| majibu | 12/13 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | SFT, Normally Black, Transmissive |
| kina cha rangi | 16.7M 40% NTSC |
| backlight | WLED , 50K hours , With LED Driver |
| wingi | 440g (Typ.) |
| kutumika kwa | Industrial |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (1 ch, 8-bit) , 30 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
