| Nambari ya Sehemu | TV097QXM-NW0 |
| Chapa | BOE |
| Ukubwa | 9.7 |
| Maombi | Pad & Tablet |
| Azimio | 1536×2048 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 6S6P |
| Kiolesura | MIPI |
| chapa ya paneli | BOE |
| mfano wa paneli | TV097QXM-NW0 |
| saizi ya paneli | 9.7" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1536(RGB)×2048, QXGA, 264PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 147.456(W)×196.608(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 152.536(W)×206.548(H) ×4.5(D) mm |
| uso | - |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1500:1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Min.)(CR≥10) |
| hali ya kuonyesha | ADS, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 35 (Max.)(Tr+Td) |
| kuonyesha rangi | 16.7M 70% NTSC |
| aina ya taa | 6S6P WLED , Without Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | 135g (Max.) |
| maombi | Pad & Tablet |
| kiolesura cha ishara | MIPI (4 data lanes) , 61 pins Connector |
| voltage ya pembejeo | 1.8/5.5/-5.5V (Typ.)(VDDI/AVDD/AVEE) |
| mazingira | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
