| Nambari ya Sehemu | UV860QUD-N50 |
| Chapa | BOE |
| Ukubwa | 86 |
| Maombi | TV Sets |
| Azimio | 3840×2160 |
| Muundo | CELL, a-Si TFT-LCD |
| Mwangaza | |
| CR | 1200:1 |
| Rangi | 1.07B |
| Mwangaza nyuma | No |
| Kiolesura | V-by-One |
| mtengenezaji | BOE |
| jina la mfano | UV860QUD-N50 |
| ukubwa wa skrini | 86 inch |
| aina ya skrini | CELL, a-Si TFT-LCD |
| nambari ya pixel | 3840(RGB)×2160 (UHD) 51PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 1895.04 × 1065.96 (H×V) |
| muhtasari(mm) | 1913.1 × 1084 × 1.35 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Antiglare (Haze 25%) |
| mwangaza | 0 cd/m² |
| uwiano wa utofautishaji | 1200 : 1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Min.)(CR≥10) |
| majibu | 8 (Typ.)(G to G) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | ADS, Normally Black, Transmissive |
| unene wa kioo | - |
| uhamishaji | 5.4% (Typ.)(with Polarizer) |
| kina cha rangi | 1.07B 99% sRGB |
| backlight | No B/L |
| wingi | 6.70Kgs (Typ.) |
| kutumika kwa | TV Sets |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| orodha ya dereva | Built-in COF 16 source + 16 gate chips |
| aina ya ishara | V-by-One 8 lane , Connector 51 pins |
| usambazaji wa voltage | 12.0V (Typ.) |
| max. ukadiriaji | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
