| Nambari ya Sehemu | V236BJ1-LE2 Rev.CA |
| Chapa | Innolux |
| Ukubwa | 23.6 |
| Maombi | TV Sets |
| Azimio | 1366×768 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | Innolux |
| mfano | V236BJ1-LE2 Rev.CA |
| ukubwa wa diagonal | 23.6 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1366(RGB)×768 [WXGA] 66PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 521.471(H)×293.184(V) mm |
| muhtasari dim. | - |
| mwangaza | - |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 8.5 (Typ.)(G to G) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| hali ya uendeshaji | AAS, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 72% NTSC |
| chanzo cha mwanga | WLED |
| uzito | - |
| iliyoundwa kwa ajili ya | TV Sets |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (1 ch, 8-bit) , 30 pins Connector |
| usambazaji wa nguvu | 12.0V (Typ.) |
| mazingira | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
