| Nambari ya Sehemu | V236BJ1-P01 Rev.CB |
| Chapa | Innolux |
| Ukubwa | 23.6 |
| Maombi | TV Sets |
| Azimio | 1366×768 |
| Muundo | CELL , a-Si TFT-LC |
| Mwangaza | |
| CR | 3000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No |
| Kiolesura | LVDS |
| mtengenezaji | Innolux |
| jina la mfano | V236BJ1-P01 Rev.CB |
| ukubwa wa skrini | 23.6 inch |
| aina ya skrini | CELL , a-Si TFT-LCD |
| nambari ya pixel | 1366(RGB)×768 (WXGA) 66PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 521.471 × 293.184 (H×V) |
| muhtasari(mm) | 535.06 × 307.34 × 1.32 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Antiglare (Haze 1%) |
| mwangaza | 0 cd/m² |
| uwiano wa utofautishaji | 3000 : 1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| majibu | 8.5 (Typ.)(G to G) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | MVA, Normally Black, Transmissive |
| unene wa kioo | 0.50+0.50 mm |
| uhamishaji | 5.6% (Typ.)(with Polarizer) |
| kina cha rangi | 16.7M 69% NTSC |
| backlight | No B/L |
| wingi | 510g (Typ.) |
| kutumika kwa | TV Sets |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| orodha ya dereva | Built-in COF 2 source chips |
| aina ya ishara | LVDS (1 ch, 8-bit) , 30 pins Connector |
| usambazaji wa voltage | 12.0V (Typ.) |
| max. ukadiriaji | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LQ235D1LW03 | SHARP | 23.6 | 1920×1080 |
| M236HJJ-L30 | Innolux | 23.6 | 1920×1080 |
| M236HJK-L3B | Innolux | 23.6 | 1920×1080 |
| P236MWF1 R2 | IVO | 23.6 | 1920×1080 |
| V236BJ1-LE2 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P01 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P01 Rev.C3 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P02 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P03 | Innolux | 23.6 | 1366×768 |
| V236BJ1-PE2 | Innolux | 23.6 | 1366×768 |
