Innolux V460H1-LS1 Rev.C6 hifadhidata, vipimo, hisa, programu www.looklcd-mk.com
LookLCD LookLCD


V460H1-LS1 Rev.C6

V460H1-LS1 Rev.C6
V460H1-LS1 Rev.C6
V460H1-LS1 Rev.C6
V460H1-LS1 Rev.C6 thumb V460H1-LS1 Rev.C6 thumb V460H1-LS1 Rev.C6 thumb
Chapa
Innolux
Ukubwa
46
Maombi
LCTV
Azimio
1920×1080
Muundo
LCM
Mwangaza
350
CR
6000:1
Rangi
1.07B
Mwangaza nyuma
WLED
Kiolesura
LVDS
In Stock
19025
Vipimo

Nambari ya Sehemu V460H1-LS1 Rev.C6
ChapaInnolux
Ukubwa46
MaombiLCTV
Azimio1920×1080
MuundoLCM
Mwangaza350
CR6000:1
Rangi1.07B
Mwangaza nyumaWLED
KiolesuraLVDS
chapa ya paneliCHIMEI INNOLUX
mfano wa paneliV460H1-LS1 Rev.C6
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli46 inch
azimio1920(RGB)×1080 , FHD
hali ya kuonyeshaSuper MVA, Normally Black, Transmissive
eneo la kazi1018.08×572.67 mm
muhtasari1076.5×634.7 mm
usoAntiglare (Haze 11%), Hard coating (3H)
mwangaza350 cd/m² (Typ.)
uwiano wa utofautishaji6000:1 (Typ.)
kuonyesha rangi1.07B (8-bit + Hi-FRC), CIE193172%
wakati wa majibu6 (Typ.)(G to G)
angle ya kutazama88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
masafa120Hz
aina ya taa4 stringsWLEDEmbedded (LED Driver)
kiolesura cha isharaLVDS (4 ch, 10-bit), 102 pins
voltage ya pembejeo12.0V (Typ.)
maombiLCTV
Mfano wa Familia
LTA460HQ16 Samsung 46 1920×1080
T460HW04 V8 AUO 46 1920×1080
V460H1-L09 Innolux 46 1920×1080
V460H1-L12 Innolux 46 1920×1080
V460H1-LE3 Innolux 46 1920×1080
V460H1-LH9 Innolux 46 1920×1080
V460H1-LS1 Innolux 46 1920×1080
V460H1-LS1 Rev.C6 Innolux 46 1920×1080
V460H1-LS2 Innolux 46 1920×1080
V460H1-LS2 Rev.C7 Innolux 46 1920×1080
