| Nambari ya Sehemu | VLT270-SBL-FHD-168 |
| Chapa | Vitrolight |
| Ukubwa | 24.4 |
| Maombi | Digital Signage Stre |
| Azimio | 1920×540 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | Vitrolight |
| mfano wa paneli | VLT270-SBL-FHD-168 |
| saizi ya paneli | 24.4" (1/2 cut of 27.0") |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1920(RGB)×540, 81PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 597.6(W)×168(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 630(W)×200(H) mm |
| uso | - |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| angle ya kutazama | 85/85/80/80 (Typ.)(CR≥10) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| mwonekano bora zaidi | - |
| wakati wa majibu | 3.8 (Typ.)(G to G) |
| kuonyesha rangi | 16.7M 72% NTSC |
| aina ya taa | WLED |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | - |
| maombi | Digital Signage Stretched Bar LCD |
| kiolesura cha ishara | LVDS (2 ch, 8-bit) Connector |
| mazingira | Operating Temp.: 0 ~ 50 °C ; - |
