| Nambari ya Sehemu | VTF231BJ02 |
| Chapa | BOE |
| Ukubwa | 23.1 |
| Maombi | Digital Signage Stre |
| Azimio | 1920×158 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | BOE |
| mfano wa paneli | VTF231BJ02 |
| saizi ya paneli | 23.1" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1920×158(RGB), 83PPI |
| muundo wa pixel | RGB Horizontal Stripe |
| eneo la maonyesho | 585.216(W)×48.158(H) mm |
| ufunguzi wa bezel | 587.5(W)×49.8(H) mm |
| saizi ya muhtasari | 597.2(W)×60.2(H) ×17.1(D) mm |
| uso | Antiglare (Haze 25%), Hard coating (3H) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya kuonyesha | ADS, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 15 (Typ.)(G to G) |
| kuonyesha rangi | 16.7M 72% NTSC |
| aina ya taa | WLED , 30K hours , With LED Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | 450g (Typ.) |
| maombi | Digital Signage Stretched Bar LCD |
| kiolesura cha ishara | LVDS (1 ch, 8-bit) , 30 pins Connector |
| voltage ya pembejeo | 12.0V (Typ.) |
| mazingira | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LQ231U1LW01 | SHARP | 23.1 | 1600×1200 |
| LQ231U1LW21 | SHARP | 23.1 | 1600×1200 |
