| Nambari ya Sehemu | WEA012864DLPP3N00003 |
| Chapa | Winstar |
| Ukubwa | 0.96 |
| Maombi | Instruments & Meters |
| Azimio | 128×64 |
| Muundo | OLED , PM-OLED |
| Mwangaza | |
| CR | |
| Rangi | Mono(Yellow) |
| Mwangaza nyuma | self |
| Kiolesura | 4-wire |
| mtengenezaji | Winstar |
| ukubwa wa skrini | 0.96 inch |
| nambari ya pixel | 128×64 149PPI |
| eneo amilifu(mm) | 21.74 × 10.86 (H×V) |
| eneo la bezel(mm) | 23.94 × 12.06 (H×V) |
| angle ya kutazama | - |
| mtazamo mzuri | Symmetry |
| kina cha rangi | Mono(Yellow) |
| wingi | - |
| kiwango cha upya | - |
| orodha ya dereva | Built-in COG SSD1306BZ |
| aina ya ishara | 4-wire SPI, I²C , 8 pins PIN |
| usambazaji wa voltage | 3.3/5.0/7.5V (Typ.) |
| max. ukadiriaji | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 80 °C |
| jina la mfano | WEA012864DLPP3N00003 |
| aina ya skrini | OLED , PM-OLED |
| mpangilio | Rectangle |
| muhtasari(mm) | 38 × 28.5 × 4.37 (H×V×D) |
| matibabu | - |
| majibu | - |
| hali ya kazi | - |
| backlight | self |
| kutumika kwa | Instruments & Meters |
| skrini ya kugusa | Without |
