| Nambari ya Sehemu | WEO012832AG |
| Chapa | Winstar |
| Ukubwa | 2.2 |
| Maombi | Handheld & PDA Instr |
| Azimio | 128×32 |
| Muundo | PM-OLED , OLED |
| Mwangaza | |
| CR | |
| Rangi | Mono(Green) |
| Mwangaza nyuma | self |
| Kiolesura | 8-bit |
| chapa | Winstar |
| ukubwa wa diagonal | 2.2 inch |
| muundo wa pixel | 128×32 59PPI |
| eneo la kazi | 55.018(H)×13.098(V) mm |
| eneo la bezel | 57.02(H)×15.1(V) mm |
| tazama mwelekeo | Symmetry |
| angle ya kutazama | - |
| rangi ya msaada | Mono(Green) |
| uzito | - |
| kiwango cha fremu | - |
| maelezo ya d-ic | COG Built-in SSD1305Z |
| aina ya kiolesura | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 24 pins FPC |
| usambazaji wa nguvu | 3.0V (Typ.) |
| mfano | WEO012832AG |
| aina | PM-OLED , OLED |
| usanidi | Rectangle |
| muhtasari dim. | 62(H)×24(V) ×2.35(D) mm |
| matibabu | - |
| wakati wa majibu | - |
| hali ya uendeshaji | - |
| chanzo cha mwanga | self |
| iliyoundwa kwa ajili ya | Handheld & PDA Instruments & Meters |
| jopo la kugusa | Without |
