| Nambari ya Sehemu | WF39BTLASDNG0 |
| Chapa | Winstar |
| Ukubwa | 3.9 |
| Maombi | Industrial Stretched |
| Azimio | 480×128 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel |
| chapa ya paneli | Winstar |
| mfano wa paneli | WF39BTLASDNG0 |
| saizi ya paneli | 3.9" (1/2 cut of 4.3") |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 480×128(RGB), 128PPI |
| muundo wa pixel | RGB Horizontal Stripe |
| eneo la maonyesho | 95.04(W)×25.34(H) mm |
| ufunguzi wa bezel | 97.04(W)×27.34(H) mm |
| saizi ya muhtasari | 105.5(W)×37(H) ×5.63(D) mm |
| uso | Glare (Haze 0%) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| angle ya kutazama | - |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| mwonekano bora zaidi | 6 o'clock |
| wakati wa majibu | - |
| kuonyesha rangi | 16.7M |
| aina ya taa | WLED , Without Driver |
| masafa | - |
| skrini ya kugusa | PCAP |
| uzito wa paneli | - |
| maombi | Industrial Stretched Bar LCD |
| kiolesura cha ishara | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
