| Nambari ya Sehemu | 70WVW5A |
| Chapa | SII |
| Ukubwa | 7.0 |
| Maombi | IA |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 400:1 |
| Rangi | 262K/16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | SII |
| mfano wa paneli | 70WVW5A |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 152.4×91.44 mm |
| muhtasari | 165.2×105.9×8.38 mm |
| uso | Antiglare |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 400:1 (Typ.) |
| kuonyesha rangi | 262K/16.2M (6-bit / 6-bit + Dithering), CIE193145% |
| wakati wa majibu | 5/11 (Typ.)(Tr/Td) |
| angle ya kutazama | 70/70/55/65 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 7S3PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
