| Nambari ya Sehemu | AA078AA01 |
| Chapa | Mitsubishi |
| Ukubwa | 7.8 |
| Maombi | IA |
| Azimio | 800×300 |
| Muundo | LCM |
| Mwangaza | 500 |
| CR | 1000:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | Mitsubishi |
| mfano wa paneli | AA078AA01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.8 inch(8/15 cut of 8.5") |
| azimio | 800(RGB)×300 |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| eneo la kazi | 184.8×69.3 mm |
| muhtasari | 207×86 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| wakati wa majibu | 12/12 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit) |
| voltage ya pembejeo | 12.0V (Typ.) |
| maombi | IA |
| AA070MC01 | Mitsubishi | 7.0 | 800×480 |
| AA070MC11 | Mitsubishi | 7.0 | 800×480 |
| AA070ME01 | Mitsubishi | 7.0 | 800×480 |
| AA070ME01-DA1 | Mitsubishi | 7.0 | 800×480 |
| AA078AA01 | Mitsubishi | 7.8 | 800×300 |
| EDMGRB8KHF | Panasonic | 7.8 | 640×480 |
| LTM07C383 | TOSHIBA | 7.8 | 480×234 |
| ND078-101A1 | SEBO | 7.8 | 1280×400 |
| AA104VH02 | Mitsubishi | 10.4 | 640×480 |
| EL240.128.45 INT | PLANAR | 4.8 | 240×128 |
| EL320.256-FD8 V2 | PLANAR | 4.8 | 320×256 |
| LM238WR2-SLA1 | LG Display | 23.8 | 3840×2160 |
| LM64C15P | SHARP | 9.4 | 640×480 |
| LQ121S1LG41 | SHARP | 12.1 | 800×600 |
| LQ64D341 | SHARP | 6.4 | 640×480 |
| LQ9D01C | SHARP | 8.4 | 640×480 |
| LTD104C11S | TOSHIBA | 10.4 | 640×480 |
| MD480L640PG4 | Panasonic | 10.4 | 640×480 |
