| Nambari ya Sehemu | AA170EC01 |
| Chapa | Mitsubishi |
| Ukubwa | 17.0 |
| Maombi | IA |
| Azimio | 1280×1024 |
| Muundo | LCM |
| Mwangaza | 600 |
| CR | 800:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | Mitsubishi |
| mfano wa paneli | AA170EC01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 17.0 inch |
| azimio | 1280(RGB)×1024 , SXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 337.92×270.336 mm |
| muhtasari | 358.5×296.5×17.4 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 600 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 262K/16.7M (6-bit / 8-bit), CIE193172% |
| wakati wa majibu | 6/19 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4 stringsWLEDWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 6/8-bit), 30 pins |
| voltage ya pembejeo | 3.3/5.0V (Typ.)(VCC) |
| maombi | IA |
| AA170EC01 | Mitsubishi | 17.0 | 1280×1024 |
| B170PW03 V0 | AUO | 17.0 | 1440×900 |
| HSD170ME13-A05 | HannStar | 17.0 | 1280×1024 |
| LM170E03-TLL1 | LG Display | 17.0 | 1280×1024 |
| LTM170EU-L21 | Samsung | 17.0 | 1280×1024 |
| LTN170CT03-004 | Samsung | 17.0 | 1920×1200 |
| LTN170CT07-G01 | Samsung | 17.0 | 1920×1200 |
| LTN170CT08-001 | Samsung | 17.0 | 1920×1200 |
| LTN170X2-L03 | Samsung | 17.0 | 1440×900 |
| M170EN04 V6 | AUO | 17.0 | 1280×1024 |
| AA104XD12 | Mitsubishi | 10.4 | 1024×768 |
| EL640.480-AG1 ET | Lumineq | 8.1 | 640×480 |
| G104X1-L03 | Innolux | 10.4 | 1024×768 |
| LQ9D024 | SHARP | 8.4 | 640×480 |
| NL6448AC33-18A | NLT | 10.4 | 640×480 |
| NL8060AC26-52D | NLT | 10.4 | 800×600 |
| NL8060BC31-02 | NLT | 12.1 | 800×600 |
| SP14Q001 | KOE | 5.7 | 320×240 |
| TX31D41VM2BAA | KOE | 12.1 | 800×600 |
| UG-5664ASYEF01 | WiseChip | 3.1 | 256×64 |
