| Nambari ya Sehemu | AM-1024600DTZQW-A6H |
| Chapa | AMPIRE |
| Ukubwa | 7.0 |
| Maombi | Industrial Outdoor H |
| Azimio | 1024×600 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| mtengenezaji | AMPIRE |
| jina la mfano | AM-1024600DTZQW-A6H |
| ukubwa wa skrini | 7.0 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 1024(RGB)×600 (WSVGA) 170PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 154.221 × 85.92 (H×V) |
| muhtasari(mm) | 164.9 × 100 (H×V×D) |
| eneo la bezel(mm) | 158 × 89.7 (H×V) |
| matibabu | Antiglare |
| mwangaza | 1000 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800 : 1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| majibu | 13/15 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | IPS, Normally Black, Transmissive |
| kina cha rangi | 16.7M |
| backlight | WLED , 50K hours , With LED Driver |
| wingi | - |
| kutumika kwa | Industrial Outdoor High Brightness |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (1 ch, 8-bit) , 20 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
