| Nambari ya Sehemu | AM-1024600-070H |
| Chapa | Other |
| Ukubwa | 7.0 |
| Maombi | CNS |
| Azimio | 1024×600 |
| Muundo | LCM |
| Mwangaza | |
| CR | |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | Amson |
| mfano wa paneli | AM-1024600-070H |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 1024(RGB)×600 , WSVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 153.6×90 mm |
| muhtasari | 165.75×105.39×3.7 mm |
| uso | |
| mwangaza | |
| uwiano wa utofautishaji | |
| kuonyesha rangi | 262K/16.7M (6-bit / 6-bit + Dithering) |
| wakati wa majibu | |
| angle ya kutazama | |
| masafa | 60Hz |
| aina ya taa | WLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit), 40 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | CNS |
