| Nambari ya Sehemu | AM-1024600ITZQW-00H |
| Chapa | AMPIRE |
| Ukubwa | 10.1 |
| Maombi | Industrial |
| Azimio | 1024×600 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | AMPIRE |
| mfano wa paneli | AM-1024600ITZQW-00H |
| saizi ya paneli | 10.1" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1024(RGB)×600, WSVGA, 117PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 222.72(W)×125.28(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 234.9(W)×143(H) ×4.9(D) mm |
| uso | Antiglare, Hard coating |
| mwangaza | 550 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 12/28 (Typ.)(Tr/Td) |
| kuonyesha rangi | 262K/16.7M 70% NTSC |
| aina ya taa | WLED , 50K hours , Without Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | - |
| maombi | Industrial |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| voltage ya pembejeo | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
