| Nambari ya Sehemu | AM-1024600LHMQW-16H |
| Chapa | AMPIRE |
| Ukubwa | 10.1 |
| Maombi | Industrial |
| Azimio | 1024×600 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | 6S6P |
| Kiolesura | LVDS |
| mtengenezaji | AMPIRE |
| jina la mfano | AM-1024600LHMQW-16H |
| ukubwa wa skrini | 10.1 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 1024(RGB)×600 (WSVGA) 117PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 222.72 × 125.28 (H×V) |
| muhtasari(mm) | 235 × 145.8 × 7.3 (H×V×D) |
| eneo la bezel(mm) | 225.92 × 128.48 (H×V) |
| matibabu | Antiglare |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500 : 1 (Typ.) (TM) |
| angle ya kutazama | 70/70/70/50 (Typ.)(CR≥10) |
| majibu | 4/12 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | - |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 262K 47% NTSC |
| backlight | 6S6P WLED , 20K hours , With LED Driver |
| wingi | TBD |
| kutumika kwa | Industrial |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (1 ch, 6-bit) , 30 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
