| Nambari ya Sehemu | AM-1024768R2TNQW-T00H |
| Chapa | AMPIRE |
| Ukubwa | 12.1 |
| Maombi | Industrial |
| Azimio | 1024×768 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | 10S5P |
| Kiolesura | LVDS |
| chapa ya paneli | AMPIRE |
| saizi ya paneli | 12.1" |
| azimio | 1024(RGB)×768, XGA, 105PPI |
| eneo la maonyesho | 245.76(W)×184.32(H) mm |
| saizi ya muhtasari | 279(W)×209(H) ×11.2(D) mm |
| mwangaza | 850 cd/m² (Typ.) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| mwonekano bora zaidi | - |
| kuonyesha rangi | 262K/16.7M |
| masafa | 60Hz |
| uzito wa paneli | - |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| mfano wa paneli | AM-1024768R2TNQW-T00H |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | - |
| uso | - |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| wakati wa majibu | 16 (Typ.)(Tr+Td) |
| aina ya taa | 10S5P WLED , 50K hours , Without Driver |
| skrini ya kugusa | PCAP |
| maombi | Industrial |
