SHARP LQ121S1LG75 hifadhidata, vipimo, hisa, programu www.looklcd-mk.com

LQ121S1LG75


Chapa
SHARP
Ukubwa
12.1
Maombi
GM
Azimio
800×600
Muundo
LCM
Mwangaza
330
CR
800:1
Rangi
16.2M
Mwangaza nyuma
WLED
Kiolesura
LVDS
In Stock
4104
Vipimo

Nambari ya Sehemu LQ121S1LG75
ChapaSHARP
Ukubwa12.1
MaombiGM
Azimio800×600
MuundoLCM
Mwangaza330
CR800:1
Rangi16.2M
Mwangaza nyumaWLED
KiolesuraLVDS
chapa ya paneliSHARP
mfano wa paneliLQ121S1LG75
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli12.1 inch
azimio800(RGB)×600 , SVGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi246×184.5 mm
muhtasari265×205×10 mm
usoAntiglare, Hard coating (3H)
mwangaza330 cd/m² (Typ.)
uwiano wa utofautishaji800:1 (Typ.)
kuonyesha rangi16.2M (6-bit + FRC), CIE193176%
wakati wa majibu30 (Typ.)(Tr+Td)
angle ya kutazama80/80/60/80 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taaWLEDEmbedded (LED Driver)
kiolesura cha isharaLVDS (1 ch, 8-bit), 30 pins
voltage ya pembejeo3.3V (Typ.)
maombiGM
