| Nambari ya Sehemu | AM-800480LATMQW-TN0H-L |
| Chapa | AMPIRE |
| Ukubwa | 5.0 |
| Maombi | Industrial |
| Azimio | 800×480 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 250:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel |
| chapa | AMPIRE |
| ukubwa wa diagonal | 5.0 inch |
| muundo wa pixel | 800(RGB)×480 [WVGA] 188PPI |
| eneo la kazi | 108(H)×64.8(V) mm |
| mwangaza | 360 cd/m² (Typ.) |
| tazama mwelekeo | - |
| angle ya kutazama | 70/70/70/50 (Typ.)(CR≥10) |
| rangi ya msaada | 16.7M 52% NTSC |
| uzito | - |
| kiwango cha fremu | 60Hz |
| aina ya kiolesura | Parallel RGB (1 ch, 8-bit) , 45 pins FPC |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| mfano | AM-800480LATMQW-TN0H-L |
| aina | a-Si TFT-LCD , LCM |
| usanidi | RGB Vertical Stripe |
| muhtasari dim. | 118.5(H)×74(V) ×5.16(D) mm |
| uwiano wa utofautishaji | 250:1 (Typ.) (TM) |
| wakati wa majibu | 15/35 (Max.)(Tr/Td) |
| hali ya uendeshaji | TN, Normally White, Transflective |
| chanzo cha mwanga | WLED [3S6P] , W/O Driver |
| iliyoundwa kwa ajili ya | Industrial |
| jopo la kugusa | PCAP |
