| Nambari ya Sehemu | AM-800480RBTMQW-TA1H-A |
| Chapa | AMPIRE |
| Ukubwa | 7.0 |
| Maombi | Industrial |
| Azimio | 800×480 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 400:1 |
| Rangi | 262K |
| Mwangaza nyuma | 3S10P |
| Kiolesura | LVDS |
| chapa ya paneli | AMPIRE |
| mfano wa paneli | AM-800480RBTMQW-TA1H-A |
| saizi ya paneli | 7.0" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 800(RGB)×480, WVGA, 133PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 152.4(W)×91.44(H) mm |
| ufunguzi wa bezel | 155.3(W)×94.3(H) mm |
| saizi ya muhtasari | 165(W)×104.44(H) ×8.06(D) mm |
| uso | - |
| mwangaza | 255 cd/m² (Typ.) |
| uwiano wa utofautishaji | 400:1 (Typ.) (TM) |
| angle ya kutazama | 70/70/70/60 (Typ.)(CR≥10) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| mwonekano bora zaidi | 6 o'clock |
| wakati wa majibu | 5/11 (Typ.)(Tr/Td) |
| kuonyesha rangi | 262K |
| aina ya taa | 3S10P WLED , 40K hours , Without Driver |
| masafa | 60Hz |
| skrini ya kugusa | PCAP |
| uzito wa paneli | TBD |
| maombi | Industrial |
| kiolesura cha ishara | LVDS (1 ch, 6-bit) , 20 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
