| Nambari ya Sehemu | TCG070WVLBA-A00 |
| Chapa | Kyocera |
| Ukubwa | 7.0 |
| Maombi | IA |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 1000:1 |
| Rangi | 262K/16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | Kyocera |
| mfano wa paneli | TCG070WVLBA-A00 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 152.4×91.44 mm |
| muhtasari | 170×111 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 262K/16.2M (6-bit / 6-bit + FRC), CIE193160% |
| wakati wa majibu | 20/10 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
| 70WVW2A | SII | 7.0 | 800×480 |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| CLAA070ND30CW | CPT | 7.0 | 1024×600 |
| HSD070IDW1-A00 | HannStar | 7.0 | 800×480 |
| HSD070IFW1-B00 | HannStar | 7.0 | 1024×600 |
| LD070WX6-SM01 | LG Display | 7.0 | 800×1280 |
| LMS700KF06 | Samsung | 7.0 | 800×480 |
| LQ070Y3DG04 | SHARP | 7.0 | 800×480 |
| PM070WL4 | E Ink | 7.0 | 800×480 |
| TCG070WVLBA-A00 | Kyocera | 7.0 | 800×480 |
| G070VW01 V0 | AUO | 7.0 | 800×480 |
| G104S1-L01 | Innolux | 10.4 | 800×600 |
| KCB6448BSTT-X5 | Kyocera | 10.4 | 640×480 |
| LM12S472 | SHARP | 12.1 | 800×600 |
| LQ057V3LG11 | SHARP | 5.7 | 640×480 |
| LQ092B5DW02 | SHARP | 9.2 | 960×160 |
| LTD104C11U | TOSHIBA | 10.4 | 640×480 |
| MXS121022010 | SANYO | 12.1 | 800×600 |
| NL128102AC28-07 | NLT | 18.1 | 1280×1024 |
| NL6448BC26-17 | NLT | 8.4 | 640×480 |
