Innolux AT043TN25 V.1 hifadhidata, vipimo, hisa, programu www.looklcd-mk.com
LookLCD LookLCD


AT043TN25 V.1

AT043TN25 V.1
AT043TN25 V.1
AT043TN25 V.1 thumb AT043TN25 V.1 thumb
Chapa
Innolux
Ukubwa
4.3
Maombi
PND
Azimio
480×272
Muundo
LCM
Mwangaza
500
CR
500:1
Rangi
262K
Mwangaza nyuma
WLED
Kiolesura
TTL
In Stock
14205
Vipimo

Nambari ya Sehemu AT043TN25 V.1
ChapaInnolux
Ukubwa4.3
MaombiPND
Azimio480×272
MuundoLCM
Mwangaza500
CR500:1
Rangi262K
Mwangaza nyumaWLED
KiolesuraTTL
chapa ya paneliINNOLUX
mfano wa paneliAT043TN25 V.1
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli4.3 inch
azimio480(RGB)×272 , WQVGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi95.04×53.856 mm
muhtasari105.5×67.2 mm
usoAntiglare
mwangaza500 cd/m² (Typ.)
uwiano wa utofautishaji500:1 (Typ.)
kuonyesha rangi262K (6-bit), CIE193150%
wakati wa majibu10/15 (Typ.)(Tr/Td)
angle ya kutazama70/70/50/70 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa9S1PWLEDWithout Driver
kiolesura cha isharaParallel RGB (1 ch, 6-bit) + SPI, 67 pins
voltage ya pembejeo1.8/3.3V (Typ.)(DVDD/AVDD)
maombiPND
