AT050TN22 V.1

AT050TN22 V.1
AT050TN22 V.1
AT050TN22 V.1
AT050TN22 V.1 thumb AT050TN22 V.1 thumb AT050TN22 V.1 thumb
Chapa
Innolux
Ukubwa
5.0
Maombi
VDP
Azimio
640×480
Muundo
LCM
Mwangaza
250
CR
500:1
Rangi
16.7M
Mwangaza nyuma
WLED
Kiolesura
TTL
In Stock
2216
Vipimo

Nambari ya Sehemu AT050TN22 V.1
ChapaInnolux
Ukubwa5.0
MaombiVDP
Azimio640×480
MuundoLCM
Mwangaza250
CR500:1
Rangi16.7M
Mwangaza nyumaWLED
KiolesuraTTL
chapa ya paneliINNOLUX
mfano wa paneliAT050TN22 V.1
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli5.0 inch
azimio640(RGB)×480 , VGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi101.568×76.176 mm
muhtasari117.65×88.43×6.6 mm
usoAntiglare
mwangaza250 cd/m² (Typ.)
uwiano wa utofautishaji500:1 (Typ.)
kuonyesha rangi16.7M (8-bit)
wakati wa majibu10/15 (Typ.)(Tr/Td)
angle ya kutazama70/70/50/70 (Typ.)(CR≥10)(L/R/U/D)
aina ya taa3S6PWLEDWithout Driver
kiolesura cha isharaParallel RGB (1 ch, 8-bit), 50 pins
voltage ya pembejeo3.3/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL)
maombiVDP
