| Nambari ya Sehemu | AT070TN04 |
| Chapa | Innolux |
| Ukubwa | 7.0 |
| Maombi | Automotive Display |
| Azimio | 480×234 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 300:1 |
| Rangi | Full |
| Mwangaza nyuma | CCFL |
| Kiolesura | TFT |
| chapa | Innolux |
| ukubwa wa diagonal | 7.0 inch |
| muundo wa pixel | 480(RGB)×234 76PPI |
| eneo la kazi | 154.08(H)×86.58(V) mm |
| eneo la bezel | - |
| mwangaza | 500 cd/m² (Typ.) |
| tazama mwelekeo | 6 o'clock |
| angle ya kutazama | 60/60/40/60 (Typ.)(CR≥10) |
| rangi ya msaada | Full color |
| uzito | 160g (Typ.) |
| kiwango cha fremu | 60Hz |
| aina ya kiolesura | TFT Specific Analog RGB , 26 pins FPC |
| usambazaji wa nguvu | 5.0/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| mazingira | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| mfano | AT070TN04 |
| aina | a-Si TFT-LCD , LCM |
| usanidi | RGB Vertical Stripe |
| muhtasari dim. | 164.9(H)×100(V) ×6(D) mm |
| matibabu | Antiglare |
| uwiano wa utofautishaji | 300:1 (Typ.) (TM) |
| wakati wa majibu | 10/20 (Typ.)(Tr/Td) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| chanzo cha mwanga | CCFL [1 pcs] , 10K hours , W/O Driver |
| iliyoundwa kwa ajili ya | Automotive Display |
| jopo la kugusa | Without |
