AT070TN07 V.A

AT070TN07 V.A
AT070TN07 V.A
AT070TN07 V.A
AT070TN07 V.A thumb AT070TN07 V.A thumb AT070TN07 V.A thumb
Chapa
Innolux
Ukubwa
7.0
Maombi
VDP
Azimio
480×234
Muundo
LCM
Mwangaza
200
CR
300:1
Rangi
Full color
Mwangaza nyuma
WLED
Kiolesura
Analog
In Stock
802
Vipimo

Nambari ya Sehemu AT070TN07 V.A
ChapaInnolux
Ukubwa7.0
MaombiVDP
Azimio480×234
MuundoLCM
Mwangaza200
CR300:1
RangiFull color
Mwangaza nyumaWLED
KiolesuraAnalog
chapa ya paneliINNOLUX
mfano wa paneliAT070TN07 V.A
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli7.0 inch
azimio480(RGB)×234
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi154.08×86.58 mm
muhtasari164.9×100 mm
usoAntiglare
mwangaza200 cd/m² (Typ.)
uwiano wa utofautishaji300:1 (Typ.)
kuonyesha rangiFull color
wakati wa majibu15/20 (Typ.)(Tr/Td)
angle ya kutazama60/60/40/60 (Typ.)(CR≥10)(L/R/U/D)
aina ya taa2S9PWLEDWithout Driver
kiolesura cha isharaTFT Specific Analog RGB, 26 pins
voltage ya pembejeo(3.3/5.0)/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL)
rohs:
maombiVDP
