| Nambari ya Sehemu | AV094Z9M-N10 |
| Chapa | BOE |
| Ukubwa | 9.4 |
| Maombi | CNS |
| Azimio | 1920×480 |
| Muundo | LCM |
| Mwangaza | 500 |
| CR | 950:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | BOE |
| mfano wa paneli | AV094Z9M-N10 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 9.4 inch |
| azimio | 1920(RGB)×480 |
| hali ya kuonyesha | ADS, Normally Black, Transmissive |
| eneo la kazi | 230.4×57.6 mm |
| muhtasari | 243.86×73.7×11.38 mm |
| uso | Clear |
| mwangaza | 500 cd/m² (Min.) |
| uwiano wa utofautishaji | 950:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193170% |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | CNS |
| AV094Z9M-N10 | BOE | 9.4 | 1920×480 |
| KCL6448HSTT-X12 | Kyocera | 9.4 | 640×480 |
| LM-CK53-22NFR | SANYO | 9.4 | 640×480 |
| LM64183P | SHARP | 9.4 | 640×480 |
| LM64P723 | SHARP | 9.4 | 640×480 |
| LM64P81 | SHARP | 9.4 | 640×480 |
| LMG5278XUFC-00T | KOE | 9.4 | 640×480 |
| LP094WX1-SLA1 | LG Display | 9.4 | 1280×800 |
| LP094WX1-SLA2 | LG Display | 9.4 | 1280×800 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| A070VW05 V2 | AUO | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| L5F30614T23 | SANYO | 8.0 | 800×480 |
| L5F30614T64 | SANYO | 8.0 | 800×480 |
| LB040Q02-TD05 | LG Display | 4.0 | 320×240 |
| LB043WQ4-TD01 | LG Display | 4.3 | 480×272 |
| LQ088H9DZ03 | SHARP | 8.8 | 640×240 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TM062RDS01 | Tianma | 6.2 | 800×480 |
