| Nambari ya Sehemu | B080EAN01.1 |
| Chapa | AUO |
| Ukubwa | 8.0 |
| Maombi | PAD |
| Azimio | 800×1280 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | AUO |
| mfano wa paneli | B080EAN01.1 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 8.0 inch |
| azimio | 800(RGB)×1280 , WXGA |
| hali ya kuonyesha | AHVA, Normally Black, Transmissive |
| eneo la kazi | 107.64×172.224 mm |
| muhtasari | 114.6×184.6×3.85 mm |
| uso | Glare (Haze 0%) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193158% |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4S5PWLEDWithout Driver |
| kiolesura cha ishara | MIPI (4 data lanes), 36 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| B080EAN02.0 | AUO | 8.0 | 800×1280 |
| B080EAN02.2 | AUO | 8.0 | 800×1280 |
| C080VW02 V0 | AUO | 8.0 | 800×480 |
| EJ080NA-04A | Innolux | 8.0 | 1024×768 |
| L5F30614T23 | SANYO | 8.0 | 800×480 |
| LD080UX1-SMA2 | LG Display | 8.0 | 1200×1600 |
| PD080SL5 | E Ink | 8.0 | 800×600 |
| PD080SY1 | E Ink | 8.0 | 800×600 |
| TM080SDH01 | Tianma | 8.0 | 800×600 |
| B101UAN01.7 HW1A | AUO | 10.1 | 1920×1200 |
| HT12X21-221 | HYDIS | 12.1 | 1024×768 |
| HV121P01-100 | HYDIS | 12.1 | 1400×1050 |
| HV121WX6-111 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-110 | HYDIS | 12.1 | 1280×800 |
| LD070WU2-SM01 | LG Display | 7.0 | 1200×1920 |
| LP097QX1-SPC2 | LG Display | 9.7 | 2048×1536 |
| LQ079L1SX02 | SHARP | 7.9 | 1536×2048 |
| LQ104X2LX05B | SHARP | 10.4 | 1024×768 |
| LT121DKXBF00 | TOSHIBA | 12.1 | 1280×800 |
