| Nambari ya Sehemu | EJ080NA-04A |
| Chapa | Innolux |
| Ukubwa | 8.0 |
| Maombi | PAD |
| Azimio | 1024×768 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 700:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | INNOLUX |
| mfano wa paneli | EJ080NA-04A |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 8.0 inch |
| azimio | 1024(RGB)×768 , XGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 162.048×121.536 mm |
| muhtasari | 183×141×3.7 mm |
| uso | Hard coating |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 700:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit) |
| wakati wa majibu | 6/14 (Typ.)(Tr/Td) |
| angle ya kutazama | 75/75/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 3S9PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 40 pins |
| voltage ya pembejeo | 3.3/11.5/22/-7V (Typ.)(VDD/AVDD/VGH/VGL) |
| maombi | PAD |
| BP080WX7-100 | BOE | 8.0 | 1280×800 |
| EJ080NA-04A | Innolux | 8.0 | 1024×768 |
| EJ080NA-04B | Innolux | 8.0 | 1024×768 |
| EJ080NA-04C | Innolux | 8.0 | 1024×768 |
| EJ080NA-05A | Innolux | 8.0 | 800×600 |
| EJ080NA-05B | Innolux | 8.0 | 800×600 |
| LB080WV4-TD02 | LG Display | 8.0 | 800×480 |
| N080ICE-GB0 Rev.C2 | Innolux | 8.0 | 800×1280 |
| TM080SV-22L03 | SANYO | 8.0 | 800×600 |
| TM080VG-22L01 | SANYO | 8.0 | 640×480 |
| LD089WX1-SL03 | LG Display | 8.9 | 1280×768 |
| LQ070M1SX01 | SHARP | 7.0 | 1200×1920 |
| LQ097L1JY01 | SHARP | 9.7 | 2048×1536 |
| LTL101AL06-W14 | Samsung | 10.1 | 1280×800 |
| LTN121AP05-302 | Samsung | 12.1 | 1280×800 |
| M101NWWB R6 | IVO | 10.1 | 1280×800 |
| N101ICG-L21 Rev.C1 | Innolux | 10.1 | 1280×800 |
| TFTMD089030 | JDI | 8.9 | 2560×1600 |
| TM090JDH01 | Tianma | 9.0 | 1280×800 |
| TPF0702002N | JDI | 7.0 | 1200×1920 |
