| Nambari ya Sehemu | B080XAN01.0 |
| Chapa | AUO |
| Ukubwa | 7.9 |
| Maombi | PAD |
| Azimio | 768×1024 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 800:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | AUO |
| mfano wa paneli | B080XAN01.0 1 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.9 inch |
| azimio | 768(RGB)×1024 , XGA |
| hali ya kuonyesha | AHVA, Normally Black, Transmissive |
| eneo la kazi | 119.808×159.744 mm |
| uso | |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193150% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 6 stringsWLEDWithout Driver |
| kiolesura cha ishara | MIPI (4 data lanes), 32 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
