| Nambari ya Sehemu | BP080WX7-100 |
| Chapa | BOE |
| Ukubwa | 8.0 |
| Maombi | PAD |
| Azimio | 1280×800 |
| Muundo | CELL |
| Mwangaza | 0 |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No B/L |
| Kiolesura | MIPI |
| chapa ya paneli | BOE |
| mfano wa paneli | BP080WX7-100 |
| aina ya paneli | a-Si TFT-LCD , CELL |
| saizi ya paneli | 8.0 inch |
| azimio | 1280(RGB)×800 , WXGA |
| hali ya kuonyesha | HFFS, Normally Black, Transmissive |
| eneo la kazi | 172.224×107.64 mm |
| muhtasari | 179.6×116.9×0.793 mm |
| uso | Hard coating (3H) |
| kioo kina | 0.25+0.25 mm |
| uwiano wa utofautishaji | 900:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193155% |
| wakati wa majibu | 24 (Typ.)(Tr+Td) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| kiolesura cha ishara | MIPI (4 data lanes), 31 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
