| Nambari ya Sehemu | B101EAN01.1 |
| Chapa | AUO |
| Ukubwa | 10.1 |
| Maombi | PAD |
| Azimio | 1280×800 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | B101EAN01.1 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.1 inch |
| azimio | 1280(RGB)×800 , WXGA |
| hali ya kuonyesha | AHVA, Normally Black, Transmissive |
| eneo la kazi | 216.96×135.6 mm |
| muhtasari | 227.9×147.8×4.6 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193150% |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4 stringsWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 36 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
| B101EAN01.1 | AUO | 10.1 | 1280×800 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101EAN01.4 | AUO | 10.1 | 1280×800 |
| B101EAN01.5 | AUO | 10.1 | 1280×800 |
| B101EAN01.6 | AUO | 10.1 | 1280×800 |
| B101EAN01.7 | AUO | 10.1 | 1280×800 |
| B101EVT03.1 | AUO | 10.1 | 1280×800 |
| B101EW02 V1 | AUO | 10.1 | 1280×720 |
| B101EW04 V0 | AUO | 10.1 | 1280×800 |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| BP070WSA-400 | BOE | 7.0 | 1024×600 |
| BP070WX6-400 | BOE | 7.0 | 800×1280 |
| CLAA070WP03XG | CPT | 7.0 | 800×1280 |
| HSD101PWW1-A00 Rev.4 | HannStar | 10.1 | 1280×800 |
| HV121WX5-120 | HYDIS | 12.1 | 1280×800 |
| LP097X02-SLQ1 | LG Display | 9.7 | 1024×768 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LQ097L1JY01A | SHARP | 9.7 | 2048×1536 |
| LQ101R1SX01A | SHARP | 10.1 | 2560×1600 |
