AUO B116XTN01.0 HW5A hifadhidata, vipimo, hisa, programu www.looklcd-mk.com
LookLCD LookLCD


B116XTN01.0 HW5A

B116XTN01.0 HW5A
B116XTN01.0 HW5A
B116XTN01.0 HW5A
B116XTN01.0 HW5A thumb B116XTN01.0 HW5A thumb B116XTN01.0 HW5A thumb
Chapa
AUO
Ukubwa
11.6
Maombi
NOPC
Azimio
1366×768
Muundo
LCM
Mwangaza
220
CR
500:1
Rangi
262K
Mwangaza nyuma
WLED
Kiolesura
eDP
In Stock
1000
Vipimo

Nambari ya Sehemu B116XTN01.0 HW5A
ChapaAUO
Ukubwa11.6
MaombiNOPC
Azimio1366×768
MuundoLCM
Mwangaza220
CR500:1
Rangi262K
Mwangaza nyumaWLED
KiolesuraeDP
chapa ya paneliAUO
mfano wa paneliB116XTN01.0 HW5A
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli11.6 inch
azimio1366(RGB)×768 , WXGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi256.125×144 mm
muhtasari278×168×3.6 mm
mtindo wa suraFlat (PCBA Flat, Depth 3.4~4.0mm)
usoAntiglare, Hard coating (3H)
mwangaza220 cd/m² (Typ.)
uwiano wa utofautishaji500:1 (Typ.)
kuonyesha rangi262K (6-bit), CIE193145%
wakati wa majibu3/5 (Typ.)(Tr/Td)
angle ya kutazama45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taaWLEDEmbedded (LED Driver)
kiolesura cha isharaeDP (1 Lane), 30 pins
voltage ya pembejeo3.3V (Typ.)
maombiNOPC
Mfano wa Familia
B116AW02 V0 AUO 11.6 1024×600
B116XAN03.1 HW0A AUO 11.6 1366×768
B116XTN01.0 HW1A AUO 11.6 1366×768
B116XTN01.0 HW5A AUO 11.6 1366×768
B116XTN02.3 HW0A AUO 11.6 1366×768
B116XTN02.3 HW4A AUO 11.6 1366×768
B116XW05 V0 AUO 11.6 1366×768
LTN116AT02-D01 Samsung 11.6 1366×768
N116BGE-L41 Innolux 11.6 1366×768
NT116WHM-N21 BOE 11.6 1366×768
