B116XAN03.1 HW0A

B116XAN03.1 HW0A
B116XAN03.1 HW0A
B116XAN03.1 HW0A
B116XAN03.1 HW0A thumb B116XAN03.1 HW0A thumb B116XAN03.1 HW0A thumb
Chapa
AUO
Ukubwa
11.6
Maombi
PAD
Azimio
1366×768
Muundo
LCM
Mwangaza
400
CR
800:1
Rangi
262K
Mwangaza nyuma
WLED
Kiolesura
MIPI
In Stock
220
Vipimo

Nambari ya Sehemu B116XAN03.1 HW0A
ChapaAUO
Ukubwa11.6
MaombiPAD
Azimio1366×768
MuundoLCM
Mwangaza400
CR800:1
Rangi262K
Mwangaza nyumaWLED
KiolesuraMIPI
chapa ya paneliAUO
mfano wa paneliB116XAN03.1 HW0A
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli11.6 inch
azimio1366(RGB)×768 , WXGA
hali ya kuonyeshaAHVA, Normally Black, Transmissive
eneo la kazi256.125×144 mm
muhtasari270.37×159.79×4.9 mm
usoAntiglare, Hard coating (3H)
mwangaza400 cd/m² (Typ.)
uwiano wa utofautishaji800:1 (Typ.)
kuonyesha rangi262K (6-bit), CIE193152%
wakati wa majibu30 (Typ.)(Tr+Td)
angle ya kutazama89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa10S3PWLEDEmbedded (LED Driver)
kiolesura cha isharaMIPI (4 data lanes), 40 pins
voltage ya pembejeo3.3V (Typ.)
maombiPAD
Mfano wa Familia
B116XAN01.0 AUO 11.6 1366×768
B116XAN03.0 HW3A AUO 11.6 1366×768
B116XAN03.1 HW0A AUO 11.6 1366×768
B116XAN03.1 HW1A AUO 11.6 1366×768
B116XTN02.3 HW0A AUO 11.6 1366×768
B116XW02 V0 AUO 11.6 1366×768
B116XW03 V1 AUO 11.6 1366×768
N116B6-L04 Innolux 11.6 1366×768
N116BGE-L42 Innolux 11.6 1366×768
NT116WHM-N31 BOE 11.6 1366×768
