B133XTN01.6 HW1A

B133XTN01.6 HW1A
B133XTN01.6 HW1A
B133XTN01.6 HW1A
B133XTN01.6 HW1A thumb B133XTN01.6 HW1A thumb B133XTN01.6 HW1A thumb
Chapa
AUO
Ukubwa
13.3
Maombi
NBPC
Azimio
1366×768
Muundo
LCM
Mwangaza
220
CR
400:1
Rangi
262K
Mwangaza nyuma
WLED
Kiolesura
eDP
In Stock
800
Vipimo

Nambari ya Sehemu B133XTN01.6 HW1A
ChapaAUO
Ukubwa13.3
MaombiNBPC
Azimio1366×768
MuundoLCM
Mwangaza220
CR400:1
Rangi262K
Mwangaza nyumaWLED
KiolesuraeDP
chapa ya paneliAUO
mfano wa paneliB133XTN01.6 HW1A
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli13.3 inch
azimio1366(RGB)×768 , WXGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi293.42×164.97 mm
muhtasari314.1×188.7×3 mm
mtindo wa suraSlim (PCBA Flat, Depth ≤3.2mm)
usoAntiglare, Hard coating (3H), Reflection 4.3% (Typ.)
mwangaza220 cd/m² (Typ.)
uwiano wa utofautishaji400:1 (Typ.)
kuonyesha rangi262K (6-bit), CIE193145%
wakati wa majibu8 (Typ.)(Tr+Td)
angle ya kutazama45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taaWLEDEmbedded (LED Driver)
kiolesura cha isharaeDP (1 Lane), 30 pins
voltage ya pembejeo3.3V (Typ.)
maombiNBPC
Mfano wa Familia
B133EW01 V0 AUO 13.3 1280×800
B133XTN01.0 AUO 13.3 1366×768
B133XTN01.2 AUO 13.3 1366×768
B133XTN01.5 AUO 13.3 1366×768
B133XTN01.6 HW0A AUO 13.3 1366×768
B133XTN01.6 HW1A AUO 13.3 1366×768
B133XTN02.1 AUO 13.3 1366×768
B133XW02 V0 AUO 13.3 1366×768
LP133WH2-TLN4 LG Display 13.3 1366×768
LTN133AT25-501 Samsung 13.3 1366×768
