| Nambari ya Sehemu | B154EW01 V9 |
| Chapa | AUO |
| Ukubwa | 15.4 |
| Maombi | NBPC |
| Azimio | 1280×800 |
| Muundo | LCM |
| Mwangaza | 180 |
| CR | 400:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | B154EW01 V9 4 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 15.4 inch |
| azimio | 1280(RGB)×800 , WXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 331.2×207 mm |
| muhtasari | 344×242.5×6.5 mm |
| mtindo wa sura | Wedge (PCBA Bent, Depth ≥5.2mm) |
| uso | Glare (Haze 0%), Hard coating (3H), Reflection 4.3% (Typ.) |
| mwangaza | 180 cd/m² (Typ.) |
| uwiano wa utofautishaji | 400:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 12/4 (Typ.)(Tr/Td) |
| angle ya kutazama | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | NBPC |
| B154EW01 V1 | AUO | 15.4 | 1280×800 |
| B154EW01 V4 | AUO | 15.4 | 1280×800 |
| B154EW01 VC | AUO | 15.4 | 1280×800 |
| B154EW02 V1 | AUO | 15.4 | 1280×800 |
| B154EW02 V2 | AUO | 15.4 | 1280×800 |
| B154EW02 V3 | AUO | 15.4 | 1280×800 |
| B154EW02 V7 | AUO | 15.4 | 1280×800 |
| B154EW08 V0 HW2A | AUO | 15.4 | 1280×800 |
| B154EW09 V1 | AUO | 15.4 | 1280×800 |
| B154EW09 V2 | AUO | 15.4 | 1280×800 |
| B133EW03 V2 | AUO | 13.3 | 1280×800 |
| B141XG09 V0 | AUO | 14.1 | 1024×768 |
| B154EW02 V3 | AUO | 15.4 | 1280×800 |
| LP156WD1-TPB1 | LG Display | 15.6 | 1600×900 |
| LP156WH3-TLT2 | LG Display | 15.6 | 1366×768 |
| LP173WF1-TLA2 | LG Display | 17.3 | 1920×1080 |
| LTN141AT16-003 | Samsung | 14.1 | 1280×800 |
| LTN170BT06-G01 | Samsung | 17.0 | 1440×900 |
| M140NWR2 R1 | IVO | 14.0 | 1366×768 |
| N154I2-L02 | Innolux | 15.4 | 1280×800 |
