| Nambari ya Sehemu | B156XTN07.0 HW1A |
| Chapa | AUO |
| Ukubwa | 15.6 |
| Maombi | Laptop |
| Azimio | 1366×768 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | |
| chapa | AUO |
| ukubwa wa diagonal | 15.6 inch |
| muundo wa pixel | 1366(RGB)×768 [WXGA] 100PPI |
| eneo la kazi | 344.232(H)×193.536(V) mm |
| eneo la bezel | - |
| mwangaza | 200 cd/m² (Typ.) |
| tazama mwelekeo | 6 o'clock |
| angle ya kutazama | 45/45/15/35 (Typ.)(CR≥10) |
| rangi ya msaada | 262K 45% NTSC |
| mtindo wa fomu | Slim (PCBA Flat, T≤3.2mm) |
| kiwango cha fremu | 60Hz |
| mfano | B156XTN07.0 HW1A (AUO10EC) |
| aina | a-Si TFT-LCD , LCM |
| usanidi | RGB Vertical Stripe |
| muhtasari dim. | 359.5(H)×223.8(V) ×3.2(D) mm |
| matibabu | Glare (Haze 0%) |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| wakati wa majibu | 8 (Typ.)(Tr+Td) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| chanzo cha mwanga | WLED , 15K hours , With LED Driver |
| iliyoundwa kwa ajili ya | Laptop |
| jopo la kugusa | Without |
| B156HW01 V7 | AUO | 15.6 | 1920×1080 |
| B156XTN02.0 | AUO | 15.6 | 1366×768 |
| B156XTN02.2 | AUO | 15.6 | 1366×768 |
| B156XTN02.4 | AUO | 15.6 | 1366×768 |
| B156XTN03.1 | AUO | 15.6 | 1366×768 |
| B156XTN03.2 | AUO | 15.6 | 1366×768 |
| B156XTN03.5 | AUO | 15.6 | 1366×768 |
| B156XTN04.1 | AUO | 15.6 | 1366×768 |
| B156XTN04.5 | AUO | 15.6 | 1366×768 |
| B156XTN05.0 | AUO | 15.6 | 1366×768 |
