| Nambari ya Sehemu | C070VW01 V0 |
| Chapa | AUO |
| Ukubwa | 7.0 |
| Maombi | CNS |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 650 |
| CR | 300:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | TTL |
| chapa ya paneli | AUO |
| mfano wa paneli | C070VW01 V0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 152.4×91.44 mm |
| muhtasari | 165×104×13 mm |
| uso | Antiglare (Haze 25%) |
| mwangaza | 650 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 6/10 (Typ.)(Tr/Td) |
| angle ya kutazama | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 2 pcsCCFLWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit), 50 pins |
| voltage ya pembejeo | 3.3/9.8/15/-7/4.2V (Typ.)(VCC/AVDD/VGH/VGL/VCOM) |
| rohs: | |
| maombi | CNS |
| C070VAN01.1 | AUO | 7.0 | 800×480 |
| C070VAN01.3 | AUO | 7.0 | 800×480 |
| C070VTN01.0 | AUO | 7.0 | 800×480 |
| C070VW01 V0 | AUO | 7.0 | 800×480 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| C070VW04 V0 | AUO | 7.0 | 800×480 |
| C070VW04 V5 | AUO | 7.0 | 800×480 |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| C070VW04 V7 | AUO | 7.0 | 800×480 |
| C070VW04 VB | AUO | 7.0 | 800×480 |
| A070VW01 V1 | AUO | 7.0 | 800×480 |
| C065GW03 V0 | AUO | 6.5 | 400×240 |
| C070FW02 V0 | AUO | 7.0 | 480×234 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| LB070WQ5-TD01 | LG Display | 7.0 | 480×240 |
| LQ065T9DR52U | SHARP | 6.5 | 400×240 |
| LQ5AW136T | SHARP | 5.0 | 320×234 |
| LQ7BW566AH | SHARP | 7.0 | 480×234 |
| M101GWT9 R3 | IVO | 10.1 | 1024×600 |
| TM062RDZG10 | Tianma | 6.2 | 800×480 |
