| Nambari ya Sehemu | C080VTN04.0 |
| Chapa | AUO |
| Ukubwa | 8.0 |
| Maombi | Automotive Display |
| Azimio | 800×480 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel |
| chapa | AUO |
| mfano | C080VTN04.0 |
| ukubwa wa diagonal | 8.0 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 800(RGB)×480 [WVGA] 115PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 175.2(H)×105.12(V) mm |
| muhtasari dim. | - |
| eneo la bezel | - |
| matibabu | Antiglare |
| tazama mwelekeo | - |
| wakati wa majibu | 15/20 (Typ.)(Tr/Td) |
| angle ya kutazama | 60/60/40/60 (Typ.)(CR≥10) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| rangi ya msaada | 262K |
| chanzo cha mwanga | WLED |
| uzito | - |
| iliyoundwa kwa ajili ya | Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | - |
| aina ya kiolesura | Parallel RGB (1 ch, 6-bit) , 60 pins Connector |
| mazingira | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
