| Nambari ya Sehemu | C084SAT01.1 |
| Chapa | AUO |
| Ukubwa | 8.4 |
| Maombi | Automotive Display |
| Azimio | 800×600 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | |
| mtengenezaji | AUO |
| ukubwa wa skrini | 8.4 inch |
| nambari ya pixel | 800×600(RGB) (SVGA) 118PPI |
| eneo amilifu(mm) | 170.88 × 128.16 (H×V) |
| mwangaza | - |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| mtazamo mzuri | Symmetry |
| kina cha rangi | 16.7M |
| wingi | - |
| kiwango cha upya | 60Hz |
| max. ukadiriaji | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 90 °C |
| jina la mfano | C084SAT01.1 |
| aina ya skrini | LCM , a-Si TFT-LCD |
| mpangilio | RGB Horizontal Stripe |
| muhtasari(mm) | - |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| majibu | 15/20 (Typ.)(Tr/Td) ms |
| hali ya kazi | AHVA, Normally Black, Transmissive |
| backlight | WLED , No Driver |
| kutumika kwa | Automotive Display |
| skrini ya kugusa | Without |
| AA084SB11 | Mitsubishi | 8.4 | 800×600 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AA084XA03 | Mitsubishi | 8.4 | 1024×768 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| M084GNS1 R1 | IVO | 8.4 | 800×600 |
| NL10276BC16-01 | NLT | 8.4 | 1024×768 |
| NL6448BC26-01 | NLT | 8.4 | 640×480 |
| T-51639D084JU-FW-A-AB | Kyocera | 8.4 | 1024×768 |
| TM084SDHG01 | Tianma | 8.4 | 800×600 |
| TM084SDHG03 | Tianma | 8.4 | 800×600 |
