| Nambari ya Sehemu | CLAA080WK0A XN |
| Chapa | CPT |
| Ukubwa | 8.0 |
| Maombi | Automotive Display |
| Azimio | 1280×720 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | |
| chapa | CPT |
| mfano | CLAA080WK0A XN |
| ukubwa wa diagonal | 8.0 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1280(RGB)×720 [WXGA] 183PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 177.024(H)×99.576(V) mm |
| muhtasari dim. | 182.8(H)×116.9(V) ×6.8(D) mm |
| eneo la bezel | 179.024(H)×101.576(V) mm |
| matibabu | Antiglare (Haze 25%), Hard coating (3H) |
| mwangaza | 600 cd/m² (Typ.) |
| uwiano wa utofautishaji | 900:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya uendeshaji | HFFS, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 70% NTSC |
| chanzo cha mwanga | WLED [9S3P] , 50K hours , W/O Driver |
| uzito | 120/230g (Typ./Max.) |
| iliyoundwa kwa ajili ya | Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
